GARNET DIRECT VENT ROOM HEATER
250-6443B October 7, 2003 Page 17
GARNET DIRECT VENT ROOM HEATER
250-6443B October 7, 2003 Page 18
FIG. 2 - VERTICAL TERMINATION
Refer to pages 25-27 for installation instructions
and requirements.
On vertical terminations use only Dura-vent Part #991.
INSTALLATION METHODS (cont'd.)
FIG. 3 - CLASS A METAL CHIMNEY
(USA only)
Refer to page 29 for installation instructions
and requirements.
Figure 2
Figure 3
VERTICAL
TERMINATION
CAP
STORM
COLLAR
FLASHING
FIRESTOP
PIPE
LENGTH
SUPPORT
BOX
TERMINATION
CAP
PA
RT #991
EXISTING
METAL
CHIMNEY
SYSTEM
TO
P
ADAPTOR
FLASHING
4" FLEX PIPE
RETRO CONNECTOR
DIRECT VENT PIPE
