Quadra-Fire MT. VERNON E2 Series - LED Color Coding Chart and Explanation

August 3, 2018 7080-163D 15
MT. VERNON E2-C
LED
Color
No. of Flashes
between pauses
Description Notes
Green
Steady ON while
priming feed tube
(max time
2 min utes)
Feed Motor is running
continuously.
(priming the feed tube)
When priming the feed system and lling the re pot, DO
NOT OVERFILL Fire pot FOR IGNITION. The unit will
automatically go into start up following the prime function.
Green
1x every 2
seconds
Unit is on standby To start appliance, follow start up sequence.
Green
Blinks
Continuously
Appliance is in the start
up/ignition sequence or in
shutdown.
During shut down, the blowers will shut off when the exhaust
temperature has cooled.
Green 1X Stage 1: Low heat BTU Range: 14,620 - 19,694 Average: 19,054
Green 2X Stage 2: Med-Low heat BTU Range: 22,102 - 23,506 Average: 22,735
Green 3X Stage 3: Med heat BTU Range: 30,778 - 32,680 Average: 31,603
Green 4X Stage 4: Med-Hi heat BTU Range: 38,576 - 42,914 Average: 40,665
Green 5X Stage 5: Hi heat BTU Range: 49,830 - 52,460 Average: 51,528
Amber
Blinks
Continuously
Appliance is in the
shutdown sequence.
During shut down, the blowers will shut off when the exhaust
temperature has cooled.
Red 1X Empty Hopper Alarm
This alarm is caused by the re going out from lack of fuel.
Reset by turning to “OFF” then turn dial to desired setting.
Red 2X Exhaust Probe Alarm
Failed component error. See troubleshoot ing section for
more information.
Red 4X Missed Ignition
There are a total of 2 tries per ignition sequence. If after
2 tries there is no rise in exhaust temperature this error
will occur. See the troubleshooting section for addi tional
information.
Red 6X Encoder Alarm
Failed Component Error: Exhaust Speed Sensor. See
troubleshooting guide for more information
Red 8X
Exhaust Over
Temperature Alarm
See troubleshooting guide for more information.
Q. LED Color Coding Chart and Explanation
The number of ashes between pauses is per one second unless otherwise indicated.
Fire Risk
Do NOT operate appliance:
• With appliance door open.
• Fire pot oor open.
Do NOT store fuel:
• Closer than required clearances to
combustibles to appliance
• Within space required for loading or ash
removal.
WARNING
