August 3, 2018 7080-163D 31
MT. VERNON E2-C
Following correction of any Alarm, turn the dial control to the OFF position, wait 10 seconds and turn back to
desired setting OR unplug the unit, wait 10 seconds then restore power.
Alarm
(LED Flashing RED)
Possible Cause Corrective Action
1 Red Flash: Empty Hopper Alarm
Hopper empty Fill the hopper
Auger jam Inspect the feed tube for jams
Vacuum switch not closing
Make sure rebox door is shut,
vacuum hose is connected
to switch and drop tube, wire
connectors are connected to
vacuum switch, control board,
hopper switch, and safety snap
disc.
Hopper lid open Close the hopper lid
Exhaust probe does not sense temperature
Secure the exhaust probe
keeping its wire away from hot
surfaces and clean the exhaust
plenum
Snap disc tripped (#3) Reset snap disc
Exhaust probe not attached to exhaust
blower properly
Secure exhaust probe to exhaust
blower housing – keeping its wire
away from hot surfaces
Exhaust path is dirty
Clean unit including the re pot,
exhaust path, and venting system
2 Red Flashes: Exhaust Probe Fail
Not connected to the control board
Connect terminal end to control
board
Failed component
Replace exhaust probe –
securing it to exhaust blower
housing – keeping wire away
from hot surfaces
4 Red Flashes: Missed Ignition
Hopper empty Fill the hopper
Feed motor doesn’t turn
Inspect feed motor circuit (hopper
lid must be closed, vacuum
switch must be closed, snap disc
closed, and feed motor must be
plugged in)
Clear jam in feed tube
Dirty appliance
Clean unit including the re pot,
exhaust path, and venting system
Igniter has no power or is defective
Check igniter lead connections or
replace igniter
Exhaust probe not properly installed
Secure exhaust probe to exhaust
blower housing – keeping its wire
away from hot surfaces
Igniter chamber plugged with debris Clean igniter chamber
6 Red Flashes: Exhaust Blower
Alarm
Wire from exhaust blower or encoder is
disconnected or shorted
Make sure wire is not damaged
/ melted and ends are fully
connected to the encoder and
control board.
Defective exhaust blower Replace exhaust blower
Defective encoder (on end of exhaust blower) Replace exhaust blower
8 Red Flashes: Exhaust Over-
Temp
Feed Motor Locked On
Repair wire(s) and replace control
board
Non-approved fuel used
Only use wood pellet fuel. Do not
enhance its performance with any
other combustible substance.
Convection blower dirty Clean impellers
