MT. VERNON AE INSERT
2. Soft Start Cycle (SS-Low / SS-Med)
Once the re is lit:
• The appliance moves into the low soft-start cycle as it
continues to build the re
• More fuel will be added
• As the re builds, the appliance will change to medium
soft-start mode
• The heating cycle begins
3. Heating Cycle ( Auto / Man - L, ML, M, MH, H)
There are two choices in the Automatic / Manual menu of
how your appliance will operate:
Automatic Mode
• The wall control will turn the heat output level up or
down depending on how far the room temperature is
from the desired temperature
• The digital display will read AUTO:M, i.e. automatic-
medium level
• As the room temperature approaches the desired
temperature, the appliance will turn down to lower
settings
• When the home reaches your set temperature, the
appliance will go into the shutdown cycle
Manual Mode
• Set the heat output setting from the main screen
• The right bottom button will read HEAT OUTPUT
• You can operate the appliance from any of the 5 levels
- On the lowest level (MAN: L) the appliance will
stay on longer, burn less fuel per hour, and will
take longer to bring the home up to your desired
temperature
- On the highest setting (MAN:H) the appliance will
burn more fuel per hour, and bring your home up to
temperature more quickly
• In Manual mode the heat output does not change
but will stay at the setting you chose until the comfort
level is reached (meaning the thermostat has been
satised). Turn to OFF to stop operation.
4. Shutdown Cycle
Once your home has reached your set temperature:
• Appliance will stop feeding fuel and allow re to
diminish
• Convection blower will continue to run until the
appliance cools to appropriate temperature
• Appliance will begin the auto-clean cycle
5. Auto-Clean Cycle
The re pot auto-clean system will cycle:
• When the appliance is rst plugged in
• When the house reaches temperature and the
appliance shuts down
• At prescribed intervals, depending on the type of fuel
selected
• When starting up after an electrical interruption
If your appliance is running and the auto-clean cycle is
initiated, the appliance will revert to shutdown cycle.
• The oor of the re pot will open and dump the ash into
the ash pan
• It takes approximately 2 minutes to complete the auto-
clean cycle
• The oor will then shut, and if the thermostat is still
calling for heat, the re will start again
• During this auto-clean cycle, the convection blower
may continue to run. The combustion blower will
continue to run.
Additional Screen Messages:
READY
It is telling you that the home is up to
temperature and doesn’t need any
heat.
- - - - -
The screen will show 5 dashes when
the wall control and the control board
are NOT communicating with each
other. Check that the wiring on the
thermostat is properly connected.
MAINTENANCE
BURN
This indicates the appliance is
operating on battery backup, prior to
the auto-clean. The maintenance burn
will keep the system from shutting
down as the appliance will not
automatically re-light in battery back-
up mode.
OFF
The AUTO/MANUAL SETTING
screen has been set to OFF. Set the
appliance to OFF when performing
periodic maintenance to prevent an
unexpected startup.
BLANK
SCREEN
The ON/OFF switch may be in OFF
position or make sure electrical power
is supplied to the appliance. Turn to
ON position.
