24 7036-187M August 13, 2018
MT. VERNON AE INSERT
H. Battery Back-up System (Optional)
• Hook up to battery terminals BEFORE you plug
battery into appliance.
• Damage to internal electronic components may occur
CAUTION
The appliance has been designed to operate on an optional
battery back-up system.
If you have frequent power outages in your region, hook
the appliance up to a 12 volt battery and it will automatically
switch to battery power in the event of a power failure. The
12 volt power cord sold as a separate accessory does not
charge the battery.
Figure 24.1
MANUAL LIGHT PROCEDURE
Press “CONTINUE”
button to start manual
lighting sequence
Current Tem: 72 F
O
CONTINUE
MANUAL LIGHT PROCEDURE
Please wait while
feed charge is loading
into firepot
MANUAL LIGHT PROCEDURE
Open door...
Manually light fuel...
Close door
Refer to owners manual for instructions on how to attach
the cable to appliance. The following are screens you will
see when using a back-up battery.
Operating on Battery Back-Up
• A battery icon appears on your wall control to let you
know you are now operating on battery power (Figure
24.2).
• Fire must be manually lit as the appliance will no longer
automatically light.
• Use only approved re starting gel to start re.
• High burn rate is no longer available on battery
back-up.
• Each level drops down one level, i.e the high burn
becomes medium-high burn and so on.
• If the battery charge falls below 10 volt it can no longer
sustain the appliance operation and the appliance will
shut down. You must disconnect and reconnect the
battery to start it up again.
Recommended Battery
• 12 volt deep cycle battery, (i.e., marine or RV type).
• A 12 volt battery cable is available through your local
dealer.
Figure 24.2
WARNING
Risk of Injury!
• Blowers may continue to run and would be exposed to
human contact.
Wall Control Display
The wall control will display the battery icon when operating
in the battery back-up mode (Figure 24.3).
MAINT BURN
73
Set at: 73
12:30 PM
HEAT OUTPUT
MENU
“Maint Burn” will display when
the thermostat has reached the
set room temperature and will
run on low until it reaches its
auto-clean cycle time.
Battery icon.
Figure 24.3
