August 13, 2018 7036-187M 9
MT. VERNON AE INSERT
Model Mt. Vernon Pellet Insert AE
Laboratory OMNI Test Laboratories, Inc.
Report No. 061-S-69-6
Type
Solid Fuel Room Appliance/Pellet Type
Insert
Standard
ASTM E1509-04, ULC S628-93 and
ULC/ORD-C1482-M1990 Room
Appliance Pellet Fuel Burning type and
(UM) 84-HUD, Mobile Home Approved.
FCC
Complies with Part 15 of FCC Rules.
Operation is subject to the following
two conditions: (1) this device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
EPA Certication #: 970-14
EPA Certied Emissions: 1.7 grams per hour
*LHV Tested Efciency: 76.9 %
**HHV Tested Efciency: 71.2 %
***EPA BTU Output: 12,500 to 40,200 / hr.
****BTU Input: 16,800 to 53,300 / hr.
Vent Size: 3 or 4 inches, “L” or “PL”
Hopper Capacity: 52 lbs.
Fuel Wood Pellets
* Weighted average LHV efciency using data collected
during EPA emissions test.
**Weighted average HHV efciency using data collected
during EPA emissions test.
***A range of BTU outputs based on EPA Default
Efciency and the burn rates from the low and high EPA
tests.
****Based on the maximum feed rate per hour multiplied
by approximately 8600 BTU’s which is the average BTU’s
from a pound of pellets.
1 Listing and Code Approvals
A. Appliance Certication B. BTU & Efciency Specications
The Quadra-Fire Mt. Vernon AE Pellet Insert meets the U.S. Environmental Protection Agency’s emission limits for pellet
inserts sold after May 15, 2015.
This pellet appliance needs periodic inspection and repair for proper operation. It is against federal regulations to operate
this pellet appliance in a manner inconsistent with operating instructions in this manual.
NOTICE: This installation must conform with local codes. In the absence of local codes you must comply with the
ASTM E1509-04, ULC S628-93, (UM) 84-HUD and ULC/ORD-C-1482-M1990.
