Quadra-Fire MT VERNON - Reference Materials; E. Component Locations

38 7036-187M August 13, 2018
MT. VERNON AE INSERT
Figure 38.1 - Feed Motor, Vacuum Switch, Exhaust Blower,
Overheat Sensor
Figure 38.2 - Power Supply, Control Board, Convection
Blower
Figure 38.3 - Heat Exchanger, Bafe, Ash Pan,
Fire pot Thermocouple & Thermocouple Cover
Baffle
Firepot
Ash Pan
Thermocouple and
Thermocouple Cover
Heat Exchanger,
Front & Back
Power Supply
Control
BoardConvection
Blower
Drop Tube
Low Fuel
Indicator
Exhaust Blower
Door Switch
Feed
Motor
Vacuum
Switch
Overheat
Sensor
Wing Nut - Securing
Overheat Sensor in
place.
Re-set
Button
Auger Optical Switch
behind Feed Motor
E. Component Locations
