August 13, 2018 7036-187M 17
MT. VERNON AE INSERT
M. Insert Removal
In the case that service or inspection is required the appliance may need to be removed from the wall.
1. Appliance must be unplugged before removal of appliance is possible. Unplug the appliance from its power source.
2. Remove insert surround from appliance, to ease the process of removal.
3. Unclip the exhaust transition from the exhaust outlet in the back of the appliance. This is what connects the venting to
the appliance. Removal of the clips will allow you to remove the appliance from the wall without damaging or adjusting
the venting.
4. Slide appliance from the wall and rotate either direction as needed.
N. Frequently Asked Questions
WARNING
Fire Risk.
• DO NOT BURN GARBAGE OR FLAMMABLE
FLUIDS SUCH AS GASOLINE, NAPHTHA OR
ENGINE OIL.
• Do NOT burn treated wood or wood with salt
(driftwood).
• May generate carbon monoxide if burn
material other than wood.
May result in illness or possible death.
ISSUES SOLUTIONS
1 Metallic noise. 1
Noise is caused by metal expanding and contracting as it
heats up and cools down, similar to the sound produced by
a furnace or heating duct. This noise does not affect the
operation or longevity of your insert.
2 Ash buildup on glass. 2 This is normal. Clean the glass.
3 Glass has turned dirty. 3
Excessive build up of ash. The lower burn settings will
produce more ash, the higher burn settings produce less.
The more it burns on low the more frequent cleaning of the
glass is required.
4 Fire has tall ames with black tails and is lazy. 4
The feed rate needs to be reduced or the re pot needs
cleaning. Heat exchanger of exhaust blower needs
cleaning.
5
Smokey start-up or puffs of smoke from the air
wash.
5
Either the re pot is dirty or there is too much fuel at start-up
and not enough air. Close down feed rate 1/4 inch at a time
until this no longer happens.
6 Large ame at start-up. 6
This is normal. Flame will settle down once the re is
established.
CONTACT YOUR DEALER for additional information regarding operation and troubleshooting.
Visit www.quadrare.com to nd a dealer.
Odors and vapors released during initial operation.
• Curing of high temperature paint.
• Open windows for air circulation.
Odors may be irritating to sensitive individuals.
CAUTION
Fire Risk.
Keep combustible materials, gasoline and other
ammable vapors and liquids clear of appliance.
WARNING
• Do NOT store ammable materials in the appliance’s
vicinity.
• DO NOT USE GASOLINE, LANTERN FUEL,
KEROSENE, CHARCOAL LIGHTER FLUID OR
SIMILAR LIQUIDS TO START OR “FRESHEN UP” A
FIRE IN THIS Appliance.
• Keep all such liquids well away from the appliance
while it is in use.
• Combustible materials may ignite.
