Quadra-Fire Santa Fe Pellet Insert - Installation into Factory-Built Fireplace

7019-230JOctober 23, 2018 11
SANTA FE PELLET INSERT
Mark area of
floor to cut
Starter hole
Keep sharp edge of
metal floor away from
power cord
F. Installation into a Factory-Built Fireplace
The following modications are permissible:
• Removal of damper or locked in open position
• Removal of smoke shelf or bafe
• Removal of ember catches
• Removal of re grate
• Removal of view screen/curtain
• Removal of doors
• Removal of factory-built replace oor
• External trim pieces which do not affect the operation
of the replace may be removed providing they can be
stored on or within the replace for reassembly if the
insert is removed.
• The permanent metal warning label provided must be
attached to the back of the replace, with screws or
nails, stating that the replace may have been altered
to accommodate the insert, and must be returned to
original condition for use as a conventional replace.
Figure 11.1
Figure 11.2
Measure and mark the metal oor for cutting. With a drill,
make a starter hole in each corner.
Figure 11.3
Using a saws-all, cut out the oor.
Figure 11.4
Place the insert into the factory-built rebox. Ensure that the
power cord can not be damaged by the sharp metal edge.
You may need to cut out a notch to accommodate the cord.
250-2061
WARNING
THIS FIREPLACE MAY HAVE BEEN ALTERED
TO ACCOMMODATE AN INSERT. IT MUST BE
RETURNED TO ITS ORIGINAL CONDITION
BEFORE USE AS A SOLID FUEL BURNING
FIREPLACE.
250-2061
Heath & Home Technologies
250-2061
5.5 in. width x 2 in. height
NON. ANOD. ALUM BLACK LETTERS ON SILVER
with 1/8 in. holes on both sides.
Black letters
Figure 11.1
• If the hearth extension is lower than the replace
opening, the portion of the insert extending onto the
hearth must be supported.
• Manufacturer designed adjustable support kit can be
ordered from your dealer.
NOTE: Refer to chimney liner manufacturer for
recommendations on supporting the liner.
Installation into replaces without a permit will
void the listing.•
• The rebrick (refractory), glass doors, screen rails,
screen mesh and log grates can be removed from a
factory-built rebox in order to gain minimum insert
opening requirements.
• Any smoke shelves, shields and bafes may be
removed from a factory-built rebox if attached with
mechanical fasteners.
• The metal oor of the factory-built rebox may be
removed to facilitate the installation of the insert only
when a 1 inch (25mm) airspace is provided between
the insert and the oor of outer wrap.
The following is only one example as there are many
different models of factory-built replaces.
NOTE: This example is for reference only. Any
modications must not compromise the structural
integrity or reduce the protection for combustible
materials.
