Quadra-Fire Santa Fe Pellet Insert - Installation into Masonry Fireplace; Prefabricated Metal Chimney Requirements

7019-230J October 23, 201812
SANTA FE PELLET INSERT
H. Prefabricated Metal Chimney
The chimney can be new or existing, masonry or
prefabricated and must meet the following minimum
requirements:
• Must be minimum 6 inch (152mm) inside diameter of
high temperature chimney listed to UL 103 HT (2100
o
F)
or ULC-S628.
• Must use components required by the manufacturer for
installation.
• Must maintain clearances required by the manufacturer
for installation.
• Refer to manufacturers instructions for installation
• This insert is listed to ASTM E 1509-12 Standard and
is approved for installation into listed factory-built zero
clearance replaces listed to UL 127 conforming to the
following specications and instructions:
• The original factory-built clearance replace chimney
cap must be re-installed after installing the approved
chimney liner meeting type UL 103 HT requirements
(2100°F) per UL 1777.
• If the chimney is not listed as meeting HT
requirements, or if the factory built replace was tested
prior to 1998, a full height listed chimney liner must be
installed from the appliance ue collar to the chimney
top.
• The liner must be securely attached to the insert ue
collar and the chimney top.
• The air ow of the factory-built zero-clearance replace
system must not be altered. The ue liner top support
attachment must not reduce the air ow for the existing
air-cooled chimney system.
• No dilution air is allowed to enter the chimney.
1. Secure the replace damper in the open position.
If this cannot be accomplished, it will be necessary
to remove the damper
2. Seal damper area of chimney around chimney
connector with a high temperature sealant or seal
insert against the face of the replace.
3. Both methods must be removable and replaceable
for cleaning and re-installation.
G. Installation into a Masonry Fireplace
All modications that can be made to a Factory Built
Fireplace can be made to a Masonry Fireplace.
In addition DO NOT remove any brick or mortar from the
existing replace.
Risk of Fire!
Follow venting manufacturer’s clearances and
instructions when installing venting system.
WARNING
• Removing oor of replace must not weaken
structure of rebox or reduce protection for
combustible materials.
• Final approval of this installation type is contingent
upon the appropriate local authority having
jurisdiction.
WARNING
NOTICE: In Canada when using a factory-built chimney it
must be safety listed, Type UL103 HT (2100oF)
[1149oC] CLASS “A” or conforming to CAN/
ULC-S629M, STANDARD FOR 650oC FACTORY-
BUILT CHIMNEYS.
