Quadra-Fire Santa Fe Pellet Insert - Default Chapter; Table of Contents

7019-230J October 23, 20182
SANTA FE PELLET INSERT
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
1 Important Safety Information .............3
A. Appliance Certication....................... 3
B. BTU & Efciency Specications ............... 3
C. Glass Specications ........................ 4
D. Electrical Rating ........................... 4
E. Mobile Home Approved ...................... 4
F. Non-Combustible Materials ................... 4
G. Combustible Materials ...................... 4
H. Sleeping Room ............................ 4
I. California - Prop65 .......................... 4
2 Getting Started ....................................5
A . Design, Installation & Location Considerations .........5
B. Thermostat Wall Control Location .............. 6
C. Tools And Supplies Needed .................. 6
D. Inspect Appliance and Components ............ 6
E. Install Checklist ............................ 7
3 Dimensions and Clearances ..............8
A. Appliance Dimensions ....................... 8
B. Clearance To Combustibles, UL and ULC........ 9
C. Minimum Opening for Masonry & Zero Clearance
Fireplaces.................................... 10
D. Hearth Extension.......................... 10
E. Floor Protection ........................... 10
F. Installation into a Factory-Built Fireplace ........ 11
G. Installation into a Masonry Fireplace .......... 12
H. Prefabricated Metal Chimney ................ 12
4 Vent Information ................................13
A. Venting Termination Minimum Requirements .... 13
B. Avoiding Smoke and Odors.................. 14
C. Negative Pressure......................... 15
D. Draft ................................... 15
E. Chimney and Exhaust Connection ............ 15
F. Equivalent Feet of Pipe ..................... 16
G. Pipe Selection Chart ...................... 16
H. Pellet Venting Charts....................... 17
5 Venting Systems ...............................18
A. Full Reline With Outside Air - Horizontal ........ 18
B. Full Reline With Outside Air - Vertical.......... 19
6 Appliance Set-Up ..............................20
A. Leveling System .......................... 20
B. Outside Air Kit Instructions .................. 20
C. Optional Grille Removal and Installation ........ 21
D. Door Handle Removal...................... 21
E. Door Removal ............................ 21
F. Adjustable Hearth Support .................. 22
G. Panel and Trim Set ........................ 23
H. Thermostat Installation ..................... 24
I. Optional Log Set Placement ................. 25
7 Mobile Home Installation ..................26
8 Reference Materials ..........................27
A. Service & Maintenance List.................. 27
B. Accessory List ............................ 29
