DIMENSIONS
Reference Description Value (mm)
A Overall length 2200
B Wheelbase 1580
C Total height (to cowl) 1340
D Seat height 780
E Distance from ground 125
F Front track 550
G Rear track 450
H Total width (at handlebars) 800
Dimensions are given in millimetres and refer to the scooter equipped with the original tyres.
The height refers to the scooter when unloaded.
BULBS
Function Type Quantity Features
Dipped headlights Halogen H8 2 12V 35 W
Full-beam headlights Halogen H8 2 12V 35 W
Front parking light Led 2 12V 1 W
Rear parking light Led 1 12V 0.2 W
Brake light Led 1 12V 1.8 W
Turn signal Led 4 12V 1.2 W
Number-plate light Incandescent 1 12V 5 W
Helmet box light Led 1 12V 0.82 W
