52
TECHNICAL DATA
BRAKING SYSTEM
Type Disc brakes, 2 front, 2 rear
Disc diameter 240 mm
CLUTCH
Type Automatic dry centrifugal
TRANSMISSION
Primary CVT
Secondary
Helical reduction gears in oil bath with
integrated differential
Final drive Timing belt
FRAME
Type Steel tubes and sheet
WEIGHTS AND LOADS
Unladen mass (including engine oil,
fi nal drive oil, engine coolant)
269 kg
Mass in running order 279 kg
Passenger capacity 2 (driver + passenger)
Maximum permissible load 500 kg
RIMS
Type Alloy
Dimensions MT14 x 2.75
TYRES
Type Tubeless
Dimensions (front and rear)
110/80-14 M/C 53P
or
110/80-14 M/C 59P
TYRE PRESSURE
Front 1.5 bar
Rear 1.5 bar
SUSPENSIONS
Front, Rear
HTS (oleo-pneumatic tilting suspen-
sion)
BATTERY
Model Sealed lead-acid, GS GTX12 BS
Voltage 12V
Amperage 10Ah
