FORM QTC2-eg1 (515)
QUANTECH
37
Unit Dimensions - Metric (Cont'd)
QTC2020T
TOP VIEW
14 DIA MOUNTING HOLES(typ)
COMPR
END
28
126
431
58
ORIGIN
Y
C
G
X
1128
815
156
28
CONTROL
PANEL
END
END CAP
WIDTH
FRONT VIEW
2774
RIGGING HOLES
(2) 76 X 38
BOTH SIDES
398
1130
1892
2466
(2) 178 X 57
FORKLIFT HOLES
BOTH SIDES
C
G
X
Z
58
86
350
970
230
25
CONTROL
PANEL
LD18692
