Quantum DXi4700 Upgrade Guide

Installing Components in the Node
Quantum DXi4700 Capacity Upgrade Guide 23
Figure 15: Removing the Cooling-Fan Assembly
1
2
3
4
5
6
Item Description
1 Cooling-fan assembly
2 Cooling fan
3 Release lever (2)
4 Guide pin on the system board (2)
5 Cooling-fan connector (6)
6 Guide pin on the chassis (6)
13. Lift the cooling-fan assembly out of the Node.
Figure 16 on the next page illustrates the interior of the DXi4700 Node with the cover removed.
