8 Unpacking the DXi6701/DXi6702
DXi6701/DXi6702 Installation and Configuration Guide
DXi6701/DXi6702
Expansion Module
Packaging
The box containing the DXi6701/DXi6702 expansion module contains the following
items:
• DXi6701/DXi6702 expansion module
• Rack mount rails
• Bezel shipping bag (contains the front bezel)
• Accessory kit, which includes the following:
• Base Expansion Module Kit – All Models:
• Adapter Kit, Rapid Rail (1)
• Screw, M4X6, FH, Phillips (4)
• Screw, 10–32 X 3/4 in., Black (2)
• Conical Spring Washer, M5, Zinc Plated (8)
• Screw FHPH 10FX.50 SSBK 100° (8)
• C13 to C14 power cord (2)
• North American power cord (2)
• SAS interconnect cable
• Storage Capacity License Certificate
• Loose Items:
• Expansion module bezel
• Drive Slot Serial Number Map
Carefully unpack and remove the components from the packing materials (see Figure 2).
