Unpacking the DXi6701/DXi6702 5
DXi6701/DXi6702
Unpacking the DXi6701/DXi6702
By following these instructions, you help ensure that the system will continue to be
safeguarded after it arrives at the installation site.
Caution: Do NOT discard the packing materials after the system is unpacked. The
packaging materials must be used if the system is relocated.
WARNING: The DXi6701/DXi6702 node and expansion module weighs 72 lbs.
(32.7 kg) and 52 lbs. (23.6 kg) respectively. A minimum of two people are
required to lift either chassis.
DXi6701/DXi6702 Node
Packaging
The box containing the DXi6701/DXi6702 node contains the following items:
• DXi6701/DXi6702 node
• Rack mount rails
• Bezel shipping bag (contains the front bezel)
• Accessory kit, which includes the following:
• Doc Kit — All models:
• Quantum Products Regulatory Documentation CD
• Registration (Warranty) card
• Terms and Conditions Document
• OST License Certificate
• Base Node Kit — All models:
• Adapter kit, Rapid Rail (1)
• Cable, CAT6, RJ45, Non-Plenum, Blue Solid, 25 ft. (2)
• Conical Spring Washer, M5, Zinc plated (8)
• Screw, M4X6, FH, Phillips (4) (Only 2 screws are required for installation. The
remaining 2 screws are extra.)
• Screw FHPH 10FX.50 SSBK 100° (8)
• Screw, 10–32 X 3/4 in., Black (2)
• C13 to C14 power cord (2)
• North American power cord (2)
•Bezel Keys
• Cable Kit QUAD 1GbE NIC — DXi6701:
• Cable, CAT6, RJ45, Non-Plenum, Blue Solid, 25 ft. (4)
To Next Page
