2 DXi6701 and DXi6702 Configurations
DXi6701/DXi6702 Installation and Configuration Guide
DXi6701 and DXi6702 Configurations
The DXi6701 and DXi6702 are available in the following configurations (see Tab l e 1):
Table 1 DXi6701 and DXi6702
Configurations
Configuration Usable Capacity
Expansion
Modules with
1 TB Drive (Adds
8 TB Usable
Capacity)**
Expansion
Modules with
2 TB Drive (Adds
16 TB Usable
Capacity)**
Rack Space
Required
DXi6701
•1 Node
• 2 or 4 RAID controller cards*
• 6 x 1 GbE Ethernet ports
• 4 x 8 Gb Fibre Channel ports
DXi6702
•1 Node
• 2 or 4 RAID controller cards*
• 2 x 1 GbE Ethernet ports
• 2 x 10 GbE Ethernet ports (optical
or Twinax)
• 4 x 8 Gb Fibre Channel ports
8 TB – – 3U for node
2U for each
expansion
module
16 TB 1 –
24 TB 2 –
24 TB – 1
32 TB 3 –
32 TB 1 1
40 TB 4 –
40 TB – 2
48 TB 5 –
48 TB 1 2
56 TB 6 –
56 TB – 3
64 TB 7 –
64 TB 1 3
72 TB 8 –
72 TB – 4
80 TB 9 –
80 TB 1 4
* DXi6701 and DXi6702 configurations with 0 or 1 expansion modules include 2 RAID controller cards. All other configurations
include 4 RAID controller cards.
** Any combination of expansion modules (with 1 TB drives or 2 TB drives) may be ordered or used for field capacity upgrades as
long as the total capacity does not exceed 80 TB. The table does not list all possible combinations.
