Quantum QXS Series

Chapter 3: Connecting Hosts
Connect the Chassis to Hosts
QX and QXS Setup Guide 103
12-, 24-, and 48-Drive Systems
Figure 96 below provides a representative illustration of the12-, 24-, and 48-Drive Systems with multiple
servers/switches.
Figure96:Connecting hosts: Switch attach: multiple servers/switches
6Gb/s
6Gb/s
S
S
A
S
S
A
Figure 96 above provides a representative illustration of the12-, 24-, and 48-Drive Systems with four
servers/multiple switches/SAN fabric.
Figure97:Connecting hosts: four servers/multiple switches/SAN fabric
Server 1
Server 2
SAN
0A
0B
4 revreS3 revreS
