INSTALLATION
Harmony Ball Return Manual – 400-254-022 16 Rev. Date 3/16
Installing the Hood Switch
1. Position both plunger switches (759-510-030) inside the hood latch bracket weldment.
They will click into place.
Figure 12, Hood Switch Installation
