QubicaAMF Harmony - Ball Entry Sensor Connections; Optional 10 Th Frame Switch

INSTALLATION
Harmony Ball Return Manual – 400-254-022 28 Rev. Date 3/16
6.9.7 BALL ENTRY SENSOR CONNECTIONS:
24. Route the sensor cable through the designated entry point. Pass the cable through the
cable restraint, but do not tighten the cable restraint.
25. Connect the conductors to JP11:
JP11
Sensor Cable
+12
Brown (BRN)
SIGN
Black (BLK)
GND
Blue (BLU)
26. Position the cable in the cable restraint so that there is no tension on the connections and
tighten the cable restraint.
6.9.8 OPTIONAL 10
TH
FRAME SWITCHES
27. Install the switches per the instructions included in the switch kit (612-300-266).
28. Connect the pinspotter cycle and mechanic call wires from the Ball Lift Control & Signal
Cable (088-000-016), or similar, to the switch conductors as detailed in the 10
th
Frame
Switch Kit instructions (400-254-003).
29. Once everything has been connected, reinstall the control unit cover and secure the five
screws.
30. Mount the control box.
31. Replace the hood.
