QubicaAMF Harmony User Manual

TROUBLESHOOTING
Harmony Ball Return Manual – 400-254-022 38 Rev. Date 3/16
Problem
Component
Checks/Solutions
Hand dryer does not operate.
Blower
Verify the fan cage is clean
and moves freely. Replace
blower. Check fuse.
Blower Cable
Check power connection to
control box. Verify the proper
voltage plug is being used.
Check fuse.
Lift does not stop when an
intrusion enters the tunnel of
the bezel.
Control Box Mode
Verify that the control box is
in Advanced mode.
Intrusion Sensor
Verify wiring connections at
both ends. Replace intrusion
sensor.
Ball does not exit.
Belt
Verify that the belt is seated
and tensioned properly.
Motor Pulley
Verify key is present.
Wear Items
Verify the condition of the v-
wheel and wear strips.
Control box continually goes
to Mechanic’s mode.
Hood Switch Circuit
Check for an interruption in
the hood switch circuit.
Ball slipping in lift.
Guide Assemblies
Shims
Clean upper and/or lower
guide assemblies and v-
wheels or replace.
Ball sticking in transition area.
Belt pops off.
Belt
 Check alignment.
 Check tension.
 Check orientation.
 Check for wear.
Motor runs in reverse.
Drive Motor
Check/replace capacitor on
motor.
