GL300W External Battery Kit User Manual
GL300WEBKUM001 -8-
2.2. Parts List
Table 3: Part List
Name Picture Description
PCU
PCU manages the power from the external
battery
. It has build in motion sensor and
external digital inputs.
Pelican 1020 Waterproof
Box
All the components except the AC-DC charger
will be put into the Pelican 1020 Waterproof Box.
Frame for GL300W and
PCU
The frame is used to fix the PCU and GL300W.
AC-
DC Charger for
External Battery
AC-DC Charger is used to charger the external
battery. Please notice that the PCU must be
removed from the external battery when
charging.
External Battery
High capability battery, 17600 mAh.
Connect Cable
This cable is used to connect GL300W to PCU and
connect external switch to PCU.
Queclink
Confidential
