NB-IoT Module Series
BC65 Hardware Design
BC65_Hardware_Design 10 / 55
2 Product Concept
2.1. General Description
BC65 is a high-performance NB-IoT module with extremely low power consumption. It is designed to
communicate with infrastructures of mobile network operators through NB-IoT radio protocols (3GPP
Rel-13 and 3GPP Rel-14). BC65 supports a certain range of frequency bands as listed below.
Table 2: Frequency Bands of BC65 Module
BC65 is an SMD type module with LCC package, and has an ultra-compact profile of 17.7 mm × 15.8 mm
× 2.2 mm. These features allow the module to be easily embedded into size-constrained applications and
provide reliable connectivity with applications.
BC65 provides abundant external interfaces (UART, ADC, etc.) and protocol stacks (UDP/TCP/MQTT,
etc.), which provide a great convenience for customers’ applications.
Due to compact form factor, ultra-low power consumption and extended temperature range, BC65 is one
of the best choices for a certain range of IoT applications, such as smart metering, bike sharing, smart
wearables, smart parking, smart city, home appliances, security and asset tracking, agricultural and
environmental monitoring, etc. It is able to provide a complete range of SMS* and data transmission
services to meet customers’ demands.
The module fully complies with the RoHS directive of the European Union.
