NB-IoT Module Series
BC65 Hardware Design
BC65_Hardware_Design 46 / 55
Figure 32: Module Bottom Dimension (Bottom View, Unit: mm)
The package warpage level of the module conforms to the JEITA ED-7306 standard.
NOTE
