Quectel BG96 TCP/IP User Manual

LPWA Module Series
BG96 TCP/IP Application Note
BG96_TCP/IP_Application_Note 45 / 52
3.8.2. Send UDP Data to Remote
3.8.3. Receive Data from Remote
+QIURC: "recv",2 //Receive data from remote.
AT+QIRD=2 //Read UDP data. One whole UDP packet will be
outputted. There is no need to specify the read
length.
+QIRD: 4,"10.7.76.34",7687 //Data length is 4. The remote IP address is
10.7.76.34 and remote port is 7687.
AAAA
OK
AT+QIRD=2 //Read data.
+QIRD: 0 //No data in buffer.
OK
AT+QISEND=2,10,"10.7.76.34",7687 //Send data to remote whose IP is 10.7.76.34 and
remote port is 7687.
>1234567890
SEND OK
3.8.4. Close a UDP Service
+QISTATE: 2,"UDP SERVICE","10.7.157.1",0,3030,2,1,2,0,"usbmodem"
OK
AT+QISEND=2,10,"10.7.89.10",6969 //Send 10 bytes data to remote whose IP is
10.7.89.10 and remote port is 6969.
>1234567890
SEND OK
AT+QICLOSE=2 //Close the service.
OK
