Quectel EG06 Series User Manual

LTE-A Module Series
EG06 Hardware Design
EG06_Hardware_Design 29 / 89
ANT_MAIN
107
IO
Main antenna
interface
50Ω impedance.
ANT_GNSS
119
AI
GNSS antenna
interface
50Ω impedance.
If unused, keep it
open.
GPIO Pins
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
WAKEUP_IN
150
DI
Sleep mode control
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
Pull-up by default.
Low level wakes up
the module.
If unused, keep it
open.
W_DISABLE#
151
DI
Airplane mode
control
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
Pull-up by default.
In low voltage level,
the module can enter
into airplane mode.
If unused, keep it
open.
GPIO1
138
IO
General purpose
input/output port
V
OL
max=0.45V
V
OH
min=1.35V
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
If unused, keep it
open.
GPIO2
139
IO
Other Pins
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
USB_BOOT
140
DI
Force the module
to enter into
emergency
download mode
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep it
open.
SLEEP_IND
144
DO
Sleep instruction
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep it
open.
RESERVED Pins
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
RESERVED
4, 6, 7, 8,
9, 11, 12,
Reserved
Keep these pins
unconnected.
