Quectel EG06 Series User Manual

LTE-A Module Series
EG06 Hardware Design
EG06_Hardware_Design 76 / 89
6.4. Current Consumption
Table 37: EG06-E Current Consumption
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
OFF state
Power down
20
uA
Sleep state
AT+CFUN=0 (USB disconnected)
0.8
mA
WCDMA PF=64 (USB disconnected)
1.6
mA
WCDMA PF=128 (USB disconnected)
1.2
mA
WCDMA PF=512 (USB disconnected)
1.0
mA
LTE-FDD PF=32 (USB disconnected)
3.3
mA
LTE-FDD PF=64 (USB disconnected)
2.1
mA
LTE-FDD PF=128 (USB disconnected)
1.5
mA
LTE-TDD PF=32 (USB disconnected)
3.3
mA
LTE-TDD PF=64 (USB disconnected)
2.1
mA
LTE-TDD PF=128 (USB disconnected)
1.5
mA
Idle state
WCDMA PF=64 (USB disconnected)
18
mA
WCDMA PF=64 (USB connected)
29
mA
LTE-FDD PF=64 (USB disconnected)
18
mA
LTE-FDD PF=64 (USB connected)
28
mA
LTE-TDD PF=64 (USB disconnected)
18
mA
LTE-TDD PF=64 (USB connected)
28
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA CH10700 @22.7dBm
445
mA
WCDMA B1 HSUPA CH10700 @22.2dBm
450
mA
WCDMA B3 HSDPA CH1338 @22.8dBm
627
mA
WCDMA B3 HSUPA CH1338 @22.3dBm
635
mA
WCDMA B5 HSDPA CH4407 @22.7dBm
540
mA
