LTE-A Module Series
EG06 Hardware Design
EG06_Hardware_Design 70 / 89
Table 33: Antenna Requirements
Frequency range: 1561MHz ~ 1615MHz
Polarization: RHCP or linear
VSWR: < 2 (Typ.)
Passive antenna gain: > 0dBi
Active antenna noise figure: < 1.5dB
Active antenna gain: > 0dBi
Active antenna embedded LNA gain: < 17dB
VSWR: ≤ 2
Efficiency: > 30%
Max Input Power: 50W
Input Impedance: 50Ω
Gain: WCDMA Band2: 2dBi ; WCDMA Band4: 2dBi ; WCDMA
Band5: 3dBi ;LTE B2:2dBi; LTE B4:2dBi; LTE B5:3dBi; LTE
B7:2dBi; LTE B12:3dBi; LTE B13:3dBi; LTE B25:2dBi; LTE
B26:3dBi; LTE B30:0dBi; LTE B66:2dBi
Cable insertion loss: < 1dB
(WCDMA B5/B6/B8/B19,
LTE B5/B8/B12/B13/B18/B19/B20/B26/B28/B29/)
Cable insertion loss: < 1.5dB
(WCDMA B1/B2/B3/B4/B9, LTE B1/B2/B3/B4/B21/B25/B66)
Cable insertion loss < 2dB
(LTE B7/B38/B40/B41/B30)
1)
It is recommended to use a passive GNSS antenna when LTE B13 or B14 is supported, as the use of
active antenna may generate harmonics which will affect the GNSS performance.
