4.9.1. W_DISABLE#
⚫ The module provides a W_DISABLE# pin to enable or disable airplane mode through hardware
operation. W_DISABLE# is pulled up by default, and driving it low will set the module to airplane
mode.
⚫ The RF function can also be enabled or disabled through software AT commands (when <fun> = 0 or
4, the RF function will be disabled. When <fun> = 1, if W_DISABLE# is at high level, then RF
function will be enabled; if it is at low level, then RF function will still be disabled.
4.10. Indication Signal
Relative interfaces’ pin descriptions are here as follows:
Table 21: Pin Definition of Indication Signal
4.10.1. Network Status Indication
The network indication pins can be used to drive network status indication LEDs. The module provides
two network indication pins: NET_MODE and NET_STATUS. The following tables describe pin definition
and logic level changes in different network status.
Table 22: Working State of the Network Connection Status/Activity Indication
Pin Name
Pin No.
I/O
Description
Comment
STATUS
20
DO
Indicate the module's operation
status
1.8 V power domain
PSM_EINT*
96
DI
External interrupt pin; Wake up the
module from PSM
Active High
If unused, keep it open.
AP_READY
19
DI
Application processor ready
1.8 V power domain.
If unused, keep it open.
NET_STATUS
21
DO
Indicate the module's network
activity status
PSM_IND*
1
DO
Indicate the module’s power saving
mode
Pin Name
Status
Description
NET_MODE
Always High
Registered on LTE
network
