Quectel EG915U Series User Manual

LTE Standard Module Series
EG915U_Series_Hardware_Design 70 / 91
Table 33: EG915U-LA Current Consumption
EG915U-LA
Description
Conditions
Typ.
Unit
OFF state
Power down
40
uA
Sleep state
AT+CFUN=0 (USB disconnected)
0.98
mA
AT+CFUN=0 (USB connected)
2.38
mA
AT+CFUN=4 (USB disconnected)
1.06
mA
AT+CFUN=4 (USB connected)
2.43
mA
EGSM @ DRX = 2 (USB disconnected)
2.20
mA
EGSM @ DRX = 5 (USB disconnected)
1.65
mA
EGSM @ DRX = 5 (USB connected)
3.07
mA
EGSM @ DRX = 9 (USB disconnected)
1.47
mA
DCS @ DRX = 2 (USB disconnected)
2.22
mA
DCS @ DRX = 5 (USB disconnected)
1.63
mA
DCS @ DRX = 5 (USB connected)
3.03
mA
DCS @ DRX = 9 (USB disconnected)
1.48
mA
LTE-FDD @ PF = 32 (USB disconnected)
3.54
mA
LTE-FDD @ PF = 64 (USB disconnected)
2.25
mA
LTE-FDD @ PF = 64 (USB connected)
3.74
mA
LTE-FDD @ PF = 128 (USB disconnected)
1.61
mA
LTE-FDD @ PF = 256 (USB disconnected)
1.32
mA
Idle state
EGSM @ DRX = 5 (USB disconnected)
13.06
mA
EGSM @ DRX = 5 (USB connected)
28.73
mA
LTE-FDD @ PF = 64 (USB disconnected)
13.05
mA
LTE-FDD @ PF = 64 (USB connected)
28.61
mA
LTE data transfer
LTE-FDD B2 @ 22.63d Bm
694
mA
