Quectel EG915U Series User Manual

LTE Standard Module Series
EG915U_Series_Hardware_Design 71 / 91
LTE-FDD B3 @ 22.88 dBm
667
mA
LTE-FDD B4 @ 22.94d Bm
718
mA
LTE-FDD B5 @ 23.01 dBm
622
mA
LTE-FDD B7 @ 22.95 dBm
797
mA
LTE-FDD B8 @ 23.17 dBm
644
mA
LTE-FDD B28 @ 23.06 dBm
627
mA
LTE-FDD B66 @ 22.81d Bm
725
mA
GPRS data transfer
GSM850 4DL/1UL @ 32.96 dBm
269
mA
GSM850 3DL/2UL @ 30.7 dBm
394
mA
GSM850 2DL/3UL @ 28.66 dBm
463
mA
GSM850 1DL/4UL @ 26.41 dBm
473
mA
GSM900 4DL/1UL @ 32.31 dBm
257
mA
GSM900 3DL/2UL @ 30.7 dBm
372
mA
GSM900 2DL/3UL @ 28.66 dBm
456
mA
GSM900 1DL/4UL @ 26.63 dBm
452
mA
DCS1800 4DL/1UL @ 29.84 dBm
174
mA
DCS1800 3DL/2UL @ 27.89 dBm
244
mA
DCS1800 2DL/3UL @ 25.85 dBm
270
mA
DCS1800 1DL/4UL @ 23.78 dBm
280
mA
PCS1900 4DL/1UL @ 29.68 dBm
179
mA
PCS1900 3DL/2UL @ 27.74 dBm
250
mA
PCS1900 2DL/3UL @ 25.66 dBm
289
mA
PCS1900 1DL/4UL @ 23.59 dBm
295
mA
GSM voice call
GSM850 PCL=5 @ 32.82 dBm
288
mA
GSM850 PCL=12 @ 19.08 dBm
113
mA
GSM850 PCL=19 @ 6.12 dBm
80
mA
