LTE Standard Module Series
EG915U_Series_Hardware_Design 83 / 91
The figures below show the package details, measured in mm.
Figure 41: Tape Specifications
Table 39:Tape Sizemm
Figure 42: Reel Specifications
W
P
T
A0
B0
K0
K1
F
E
44
32
0.35
20.2
24
3.15
6.65
20.2
1.75
