Quectel FGH100M - Page 18

Wi-Fi Module Series
FGH100M_Hardware_Design 18 / 41
GPIO6
16
DIO
General-purpose
input/output
GPIO7
30
DIO
General-purpose
input/output
GPIO8
29
DIO
General-purpose
input/output
GPIO9
28
DIO
General-purpose
input/output
GPIO10
27
DIO
General-purpose
input/output
RF Antenna Interface
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
ANT_WIFI
40
AIO
Wi-Fi antenna
interface
50 Ω impedance.
Control Signals
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
WAKEUP_IN
6
DI
Wakes the module
VBAT
RESET_N
8
DI
Resets the module
Active low.
A test point is
recommended to be
reserved if unused.
RESERVED Pins
Pin Name
Pin No.
Comment
RESERVED
9, 37
Keep them open.
