Quectel L76 Hardware Design

GNSS Module Series
L76&L76-L_Hardware_Design 12 / 59
For more information about GNSS constellation configuration, see document [1].
1.3. Performance
Table 2: Product Performance
2
Room temperature, all satellites at -130 dBm.
Galileo
E1



E5a
-
-
-
BeiDou
B1I



B2a
-
-
-
GLONASS
L1



IRNSS
L5
-
-
-
SBAS
L1



Temperature
Range
Operating temperature range: -40 °C to +85 °C
Storage temperature range: -40 °C to +90 °C
Physical
Characteristics
Size: (10.1 ±0.15) mm × (9.7 ±0.15) mm × (2.5 ±0.20) mm
Weight: Approx. 0.6 g
Parameter
Specification
L76
L76-L
L76-L(L)
Power Consumption
2
Acquisition
25 mA
31 mA
31 mA
Tracking
15 mA
31 mA
31 mA
Standby mode
0.5 mA
0.5 mA
0.5 mA
Backup mode
7 μA
8 μA
8 μA
Sensitivity
Acquisition
-148 dBm
-149 dBm
-149 dBm
Reacquisition
-160 dBm
-161 dBm
-161 dBm
NOTE
