Table 44: BG950A-GL GNSS Current Consumption
Table 45: BG951A-GL GNSS Current Consumption
7.4. ESD
The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject
BG950A-GL
Description
Conditions
Typ.
Unit
Searching
(AT+CFUN=0)
Cold start @ Passive antenna
TBD
mA
Hot start @ Passive antenna
TBD
mA
Lost state @ Passive antenna
TBD
mA
Tracking
(AT+CFUN=0)
Instrument environment @ Passive antenna
TBD
mA
Open sky @ Real network, Passive antenna
TBD
mA
Open sky @ Real network, Active antenna
TBD
mA
BG951A-GL
Description
Conditions
Typ.
Unit
Searching
(AT+CFUN=0)
Cold start @ Passive antenna
TBD
mA
Hot start @ Passive antenna
TBD
mA
Lost state @ Passive antenna
TBD
mA
Tracking
(AT+CFUN=0)
Instrument environment @ Passive antenna
TBD
mA
Open sky @ Real network, Passive antenna
TBD
mA
Open sky @ Real network, Active antenna
TBD
mA
