LTE Standard Module Series
EG21-G Mini PCIe Hardware Design
EG21-G_Mini_PCIe_Hardware_Design 40 / 54
1. In GPRS 4 slots TX mode, the maximum output power is reduced by 3.0dB. The design conforms to
the GSM specification as described in Chapter 13.16 of 3GPP TS 51.010-1.
2. EG21-G Mini PCIe supports LTE-FDD B25, while PA QM77031 in the module does not support
LTE-FDD B25 in fact. Qorvo has confirmed that the SAW integrated in the PA can support LTE-FDD
B25, so the band is added to the module. However, the maximum power of channel 26640~26689
will be reduced by 2.5db at 75°C .
