7 Dimensions and Packaging
7.1. General Description
This chapter mainly describes mechanical dimensions as well as packaging specification of EG21-G Mini
PCIe module. All dimensions are measured in millimeter (mm), and the dimensional tolerances are
±0.05mm unless otherwise specified.
7.2. Mechanical Dimensions of EG21-G Mini PCIe
8.34 6.39 6.39
2.05
30.00±0.20
50.95±0.20
7.45
32.00
2.15 8.25
1.50
15.95
11.15
1.652.35
2.55
0.25
0.60
0.80
1.00±0.10
2.45±0.20
1.45
1.952.05
0.25
2.55
0.60
24.202.90
29.000.50
Top
Side
Bottom
0.80
2.90
2.60
33.48
10.05
28.800.58
Figure 19: Mechanical Dimensions of EG21-G Mini PCIe
