LTE Module Series
EG21-G Hardware Design
EG21-G_Hardware_Design 84 / 100
Direction of feed
Cover tape
13
100
44.5
+0.20
-0.00
48.5
Figure 47: Tape and Reel Specifications
Carrier tape
packing module
Carrier tape
unfolding
1083
Figure 48: Tape and Reel Directions
