Quectel M35 - Electro-static Discharge

GSM/GPRS Module Series
M35 User Manual
M35_User_Manual Confidential / Released 69 / 85
Table 31: The ESD Endurance (Temperature: 25ºC , Humidity: 45%)
Tested Point
Contact Discharge
Air Discharge
VBAT,GND
±5KV
±10KV
RF_ANT
±5KV
±10KV
TXD, RXD
±2KV
±4KV
Others
±0.5KV
±1KV
