GSM/GPRS/GNSS Module Series
MC60 Series Hardware Design
MC60_Series_Hardware_Design Confidential / Released 100 / 114
6.3. Top and Bottom Views of the Module
Figure 57: Top Views of MC60 and MC60E
Figure 58: Bottom Views of MC60 and MC60E
These are design effect drawings of MC60 and MC60E modules. For more accurate pictures, please refer
to the module that customers get from Quectel.
NOTE
Quectel
Confidential
