GSM/GPRS/GNSS Module Series
MC60 Series Hardware Design
MC60_Series_Hardware_Design Confidential / Released 95 / 114
When the GSM of MC60 module is in sleep mode, Bluetooth cannot enter into the SCAN mode.
Table 47: BT Current Consumption of MC60E Module
The datas are tested when turning off traditional Bluetooth and advertising BLE only.
5.5. Electrostatic Discharge
Although the module is generally protected against Electrostatic Discharge (ESD), ESD protection
precautions should still be emphasized. Proper ESD handling and packaging procedures must be applied
throughout the processing, handling and operation of any applications using the module.
The measured ESD values of the module are shown in the following table.
Full function (AT+CFUN=1)
Disable from both
transmitting and receiving
RF signals (AT+CFUN=4)
Minimum function
(AT+CFUN=0)
