Quectel MC60 Series User Manual

GSM/GPRS/GNSS Module Series
MC60 Series Hardware Design
MC60_Series_Hardware_Design Confidential / Released 94 / 114
GPRS Class 12 is the default setting. The GSM module can be configured from GPRS Class 1 to Class
12. Setting to lower GPRS class would make it easier to design the power supply for the GSM module.
Table 45: Current Consumption of GNSS part
Parameter
Conditions
Typ.
Unit
I
VCC
@Acquisition
@VCC=3.3V (GPS)
25
mA
I
VCC
@Tracking
@VCC=3.3V (GPS)
19
mA
I
VCC
@Acquisition
@VCC=3.3V (GPS+GLONASS)
29
mA
I
VCC
@Tracking
@VCC=3.3V (GPS+GLONASS)
22
mA
I
VCC
@Standby
@VCC=3.3V
0.3
mA
I
BCKP
@backup
@V_BCKP=3.3V
14
uA
The tracking current is tested in following conditions:
 For Cold Start, 10 minutes after First Fix.
 For Hot Start, 15 seconds after First Fix.
Table 46: BT Current Consumption of MC60 Module
GSM State
BT State
Current Consumption
IDLE
IDLE
13.02mA
IDLE
SCAN
32.4mA
IDLE
CONNECT
19.08mA
SLEEP
IDLE
1.31mA
SLEEP
CONNECT
12.6mA
NOTE
NOTE
Quectel
Confidential
