5 Electrical, Reliability and Radio
Characteristics
5.1. Absolute Maximum Ratings
Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are
listed in the following table:
Table 40: Absolute Maximum Ratings
Parameter
Min.
Max.
Unit
VBAT
-0.3
+4.73
V
GNSS_VCC
-0.3
+4.5
V
Peak Current of Power Supply (VBAT)
0
2
A
RMS Current of Power Supply (VBAT, during one
TDMA-frame)
0
0.7
A
Voltage at Digital Pins
-0.3
3.08
V
Voltage at Analog Pins
-0.3
3.08
V
Voltage at Digital/analog Pins in Power Down Mode
-0.25
0.25
V
