2 Product Overview
SG368Z series is Quectel’s new generation of Linux/Android smart module. It is an SMD module with
compact packaging and it supports built-in high performance ARM Mali G52 GPU, multiple audio and
video codecs, and multiple audio and video input/output interfaces as well as abundant GPIO interfaces.
With these, the module is engineered to meet most of the demands of M2M applications, for instance:
⚫ IoT gateways
⚫ smart commercial displays
⚫ AI industrial automation
⚫ security surveillance
⚫ NAS
⚫ NVR/DVR
Table 2: Basic Information
2.1. Frequency Bands and Functions
Table 3: Frequency Bands and Functions
SG368Z Series
Packaging type
LGA
Pin counts
453
Dimensions
46.0 × 42.0 × 3.15 mm
Weight
SG368Z-WF: approx. 13.1 g
SG368Z-AP: approx. 12.8 g
Models
SG368Z-WF, SG368Z-AP
Wireless Network Type
SG368Z-WF
SG368Z-AP
Wi-Fi 802.11a/b/g/n/ac
2402–2482 MHz
-
