Smart Module Series
SG368Z_Series_Hardware_Design 55 / 113
4.9. ADC Interfaces
The module provides 5 ADC interfaces which support up to 10-bit resolution.
Table 21: Pins Description of ADC Interfaces
4.10. Video Output Interfaces
The module has a built-in VOP controller and it has three output ports:
Port 1: Supports HDMI, MIPI DSI0, MIPI DSI1 and eDP video output
Port 2: Supports HDMI, MIPI DSI0, MIPI DSI1, eDP and LVDS video output
Port 3: Supports LVDS, RGB*, BT1120*, BT656* video output
Each port only supports one kind of video signal. The module supports triple-screen display and the three
screens can support different video signal.
The module supports multiple video display interfaces:
1 group of HDMI interface: supports HDMI 2.0, with the maximum output resolution up to 4096 ×
2160 @ 60 fps
1 group of MIPI DSI0 interface: supports MIPI 1.2, with the maximum output resolution up to 1920 ×
1080 @ 60 fps; it can be multiplexed into LVDS interface, with the maximum output resolution up to
1280 × 800 @ 60 fps
1 group of MIPI DSI1 interface: supports MIPI 1.2, with the maximum output resolution up to 1920 ×
1080 @ 60 fps. MIPI DSI0 and MIPI DIS1 can be combined to support Dual-MIPI, with the maximum
output resolution up to 2048 × 1536 @ 60 fps
1 group of eDP interface: supports eDP V1.3, with the maximum output resolution up to 2560 × 1600
@ 60 fps
Pin Name
Pin No.
I/O
Description
Comment
ADC2
218
AI
General-purpose ADC interface
Input voltage range: 0~1.8 V
ADC4
233
AI
General-purpose ADC interface
ADC5
228
AI
General-purpose ADC interface
ADC6
223
AI
General-purpose ADC interface
ADC7
213
AI
General-purpose ADC interface
