Table 38: Wi-Fi Receiving Performance
802.11ac @ VHT40
MCS 9
12 dBm ±3 dB
802.11ac @ VHT80
MCS 0
15 dBm ±3 dB
802.11ac @ VHT80
MCS 9
12 dBm ±3 dB
Bands
Standards
Speed Rates
Sensitivity (dBm)
2.4 GHz
802.11b
1 Mbps
-96
802.11b
11 Mbps
-86
802.11g
6 Mbps
-90
802.11g
54 Mbps
-73
802.11n @ HT20
MCS 0
-88
802.11n @ HT20
MCS 7
-69
802.11n @ HT40
MCS 0
-85
802.11n @ HT40
MCS 7
-67
5 GHz
802.11a
6 Mbps
-90
802.11a
54 Mbps
-73
802.11n @ HT20
MCS 0
-89
802.11n @ HT20
MCS 7
-70
802.11n @ HT40
MCS 0
-86
802.11n @ HT40
MCS 7
-67
802.11ac @ VHT20
MCS 0
-90
802.11ac @ VHT20
MCS 8
-68
802.11ac @ VHT40
MCS 0
--87
802.11ac @ VHT40
MCS 9
-63
802.11ac @ VHT80
MCS 0
-83
