Smart Module Series
Smart_EVB_G5_User_Guide 16 / 66
J1203
J1204
Figure 4: Bottom View for Component Placement of Smart EVB G5
Table 4: Components & Functions of Smart EVB G5
Components
RefDes.
Description
Power supply
J0201
Power jack on the EVB
Typical power supply: +5 V
J0202
Li-polymer battery connector
Typical power supply: +3.7 V
Power switches
S0201
Select DC power supply or battery power supply
S0202
VBAT on/off control
PWRKEY
S0502
Power key (push button)
Turn on/off the module
RESET
S0503
Reset button (push button)
Reset the module
VOL DOWN
S0504
Turn the volume down
