Smart Module Series
Smart_EVB_G5_User_Guide 27 / 66
The following table describes the pin definition of the two B2B connectors J0101 and J0102.
Table 9: Pin Definition of B2B Connector J0101
Pin No.
Pin Name
1, 11, 37, 71, 83, 90, 94, 101, 103, 104, 109111, 116, 122,
127129, 134, 139, 140
GND
2
LCD_RST1
3
UART1_CTS
4
GPIO5
5
UART1_RXD
6
INT_CC
7
UART1_RTS
8
TP2_HDMI_RST
9
UART1_TXD
10, 16, 21, 23, 2527, 29, 3133, 35,39, 4144, 4648, 51,
55, 57, 6264,97, 118, 130
NC
12, 14
VDD_3V3
13
UART2_CTS
15
UART2_RXD
17
UART2_RTS
18
GPIO_1
19
UART2_TXD
20
GPIO2
22
GPIO3
24
GPIO4
28
TP0101
30
TP0102
