. SummaryⅡ
3
Form2-2: key function table
Control panal key Function description
【HOME】 Make the terminal device return to work point, or set the work point.
【FILE/EDIT】 Enter file edit interface（new/edit/delete）
Z / Z Control the axis’coordinate
← / → Move the cursor towards leftside or rightside.
【ORG】 Move the terminal device to mechanical origin（0.
【PG/CLEAN】 Enter parameter setting interface
【ENT】
Save the setting parameters
Clear the circular processing times
【ESC】
1. Return to file processing interface but not save the set parameters.
2. Into the testing interface, test the axis’s function
【START/PAUSE】 Start or pause the processing file.
【FEED】 Control feeding solder
NOTE:
←, FILE and EDIT keys are at the same key.
→, PG and CLEAN keys are at the same key. (PG is parameter.)
